Fighterman_FFRCさんのイラストまとめ

Gripen E s/n 6002 from above

New GCAP Graphcis released by @BAESystemsAir

Very cool geometric camo design, though unlikely to become reality

L3Harris released some close up shots of their NGJ-LB(Next Generation Jammer Low Band) Jammer pod.

Intresting looking

F-16XL Wild Weasel and F-16XL Interceptor https://t.co/FaDVmDm8hp

The F-35A Demo Team Flies in Formation with the Belgian F-16 Solo Display Team

USAF photo by Staff Sgt. Thomas Barley

F-35A Demo Team flies in formation with a Belgian Air Force F-16 Solo Display 'Dream Viper' and a P-51 Mustang on Sept 10, 2022, Kleine Brogel Air Base, Belgium.

📷 USAF photo by Staff Sgt. Thomas Barley

Patent images of the updated Sukhoi Su-75 Checkmate fighter

Single Seat, Twin-Seater, as well as an Unmanned drone version

-Nose cone is stealthier with sawtooth treatment
-Wing root shape changes
-Flaperon is a lot bigger and extends alot more to the rear
-aft-strakes extends to the side more, strake flaps size also increased
-the entire Vertical stablizer base assembly has changed, air cooling… https://t.co/PbriVW6H6h

-Nose cone is stealthier with sawtooth treatment
-Canopy frame is also refined to lower RCS
-Wing root shape changes
-Flaperon is a lot bigger and extends alot more to the rear
-aft-strakes extends to the side more, strake flaps size also increased

To sum up, it should fly… https://t.co/RAaiohvTyo

-Nose cone is stealthier with sawtooth treatment
-Canopy frame is also refined to lower RCS
-Wing root shape changes
-Flaperon is a alot bigger and extends alot more to the rear
-aft-strakes extends to the side more, strake flaps size also increased

To sum up, it should fly… https://t.co/QGWzvqMDlP
