A Marshall technician climbs inside one of the cavities that will carry the liquid oxygen through the RP-1 tank to the F-1 engines.

Cartoon by the Instrumentation Lab depicting the Apollo astronauts on a fully automated flight.
Source: Draper

A few Space authors who are kind, helpful and knowledgeable.
@ChasingMoonBk
@davidhitt
@rjurek
Twitter can be a challenging platform to navigate but these 3 are modest and enthusiastic.

Ive not seen these images before and I shouldn’t be surprised by them. Ken Mattingly training at JSC.
Left: Emergency egress training in case the Command Module splashed down in its stable 2 position.
Middle: Deep space EVA on the service module.

I’ve always struggled to visualise how the Apollo crew transferred from the CM to the LM. Struggle over, I can now see why the instrumentation panel was cutaway.
Source: Fine Art America

One of my favourite Apollo facts. If the service module hydrogen tank was filled with ice and stored at 70 degrees F, it would take 8.5 years for the ice to melt. If a car tire leaked at these rates, it would take 30 million years to go flat.
Source: George Low.
