Sometimes I design ships. Most times I design how to design ships. Tweets not representative of employer or client policy. She/Her/Hers. @r-p-one on the blue.

フォロー数：1277 フォロワー数：10756
# cgi

A possible RAN variant of the Type 24. The Mk41s use up a lot of the topweight allowance on this one.

3 35
2020-09-13

First variant of the Type 24; what seems to have been the RN option, with GWS-25, Exocet MM40, 114mm and two Lynx in a large hangar. Looks quite mean with those missiles up front!

6 46
2020-08-16

OK, calling this complete. RN Type 24 frigate, original MoD design. Shown with 4.5" gun, 4 x Exocet, 4 x double lightwight Sea Wolf with autoloaders & 2 x lightweight directors. 2 x twin 30mm guns, 2 x triple torpedo tubes and a flight deck capable of taking Sea King.

2 35
2020-08-04

I couldn't let the day finish without reminding everyone of this really interesting study carried out by

14 86
2020-07-26

OK, good enough. On to other projects. 3000t, 39 knots. 74.6MW advanced GT plant driving superconducting motors. Aluminium construction. 12 x large ASW/Antiship Missiles and space for 24 TEU sized combat system modules. 2 SH-60.

16 107
2020-07-25

Coming soon... not my idea, but a US Navy study from the '70s. Guess the speed. Go on, guess.

6 60
2020-07-21

Vaguely terrifying that this time next year it will have been two decades since I graduated from the UCL course that I now teach on...

0 14
2020-07-13

2) Wind assistance, in the form of kites, quite possibly. We at UCL have looked at a few more unusual options though!

0 0
2020-07-01

Ahh, the generative art of entering a very wrong value for length on a hullform generator:

2 22
2020-06-14
