It printed, it holding and it is posable, good going, me

The hip joint took some mental gymnastics to figure it out. I hope it work.

This is so difficult to draw in CAD.
What kind of shape is this?
How does the line even flow?
Whic idiot designed this?
Oh... me.

#3dprinted #actionfigures

Slim torso with Version 7 joints

Version 7 joint concept
-Load bearing parts can be printed separately
-Part dimensions are a lot less limited by minimum wall thickness
-Joints can be made anywhere
-Less parts
- Requires more glue
- Nuts permanently attached. Damaged nuts will mean total loss of that part.

4 reference planes for half a torso.... What have I got myself into?

Details are in, as much as I can cram in FDM 3D printing method anyway.
@kriegsfront #3Dprinting #actionfigures

Large shapes are in place. Adding details later. Now I will go watch The Witcher SS2
@kriegsfront #3Dprinting #actionfigures

Tranforming toy for Bangkok Design Week is coming along. #BKKDesignWeek #3Dprinting

You guys are very lucky becuase I thought I have lost the files
I made a few updates to make it print better but not much I can do without total redesign. If you attempt this project, expect a lot of filing and a bit more than necssary support removal. Release, soon

#3Dprinting
