# showcase madewithfreecad fc3d floss foss opensource cad 3dcad 3dprinting moi3d gcad3d milling noob bambuko linkstage3 linkdaily mcad boat design nurbs ダイの大冒険 3dプリンター anycubic sheet metal lasercut k40 synthdiy kicad wip cnc grbl

"ソリッドを平面で切断する - XSim" - https://t.co/5qUFEVgAJ8

5 22
2022-02-14

Zebra are a bit influenced by the FreeCAD tessellation, is a bit ugly but here is, you can have an interactive B-spline comb view when you use the sketcher Workbench

0 2
2022-02-08

Although not my best design, because it's a dust-shoe and i have spend waaaaaay too much time on it.

0 7
2022-01-29

Inspired ‘s efforts to design a pen plotter, I designed a decent pen plotter addon for the ender 3 v2. Files going up later today.

3 12
2022-01-20

With more cross section curves, the green surface continuity is made with cross sections and Gordon in the red one with BlendSurface command and the blue is blended inside the FreeCAD result still far from a good result but not bad for a first try as a continuity

1 10
2022-01-09

Green surface made with via code and Red surface created with and command surface from network curves created with gCAD3D. and second image the same curves used in to generate a gordon surface. The deb archive is only 1.6Mb. 😱

1 9
2021-12-30


Animated steam locomotive modeled by '#bambuko'
"Started modelling it in the days of 0.19 and continued until now it is all in branch and uses Assembly 3."
https://t.co/s7I5RBdQ5F

14 99
2021-12-26

I will add two or three more details and I can switch to another model and learn something new with this project has several errors due to the various tests done to understand the workflow, and I still have a lot to learn.

4 13
2021-12-14

I did the final test, with surfaces and b-spline curves and after this object made with surfaces and joined in a perfect solid with you can do everything .. free form modelling IGES exported and opened in other application :)

12 40
2021-12-07

ビショップ•フェンブレン
頭のとこのダイヤ形は苦戦しました。プリミティブの変形でイロイロ試したけど作れなかったから結局３面スケッチ描いて面張しましたよ。
三日月は五角形断面のスイープで作ってます。




0 1
2021-12-07

seem very good from the wiki documentation, I will check out better in the next days
https://t.co/KpczX1rnrH
https://t.co/1riD9aeH9A

5 31
2021-11-28

je viens de remarquer l'option de profondeur par passe, par défaut donne le diamètre de la fraise, 3mm c'est un peut trop, 0.25 j'ai bon pour de l'alu ?

0 0
2021-07-26

The following project uses BlenderBIM for modeling, and FreeCAD for annotation and documentation.

https://t.co/8iDulJcDx1

10 35
2021-05-30

This is a theory math but in the CAD and other application this is composed by few surfaces like these, this is a try of your object in Nurbs and opened in FreeCAD and exported for Blender that looks nice and is composed by the same surfaces, you can use subdivisions surfaces

1 2
2021-05-05

Still training on
First parametric Book Box with Key !
Adapted from BasementLaser's svg

4 18
2021-04-29

FreeCAD 0.19 is finally officially out! Grab your copy at https://t.co/B3pMKkdBmU or read the releases notes at https://t.co/TYcIHlgEvN

86 235
2021-03-24

To all the synth designers, I am putting together a library with all the common 3.5mm jack footprints and 3D models in it for KiCAD. Will have a public repository and hopefully try and merge into the kiCAD libraries. Coming soon!

37 253
2021-03-18

Also experimenting with FreeCAD designing parts for an ongoing project that you'll eventually see on YouTube when I get my act together. Here's some teasers from my very first CAD-drawn 3D model :-)

3 25
2020-12-01
