What sparks and what gets damaged over the kerbs?
Sparks are from titanium skid blocks used to protect the underside of the car. A large block is used in the most vulnerable point at the front of the plank.
There's also Ti skid blocks in the front wing

Some archive @scarbstech Renault's Tuned Mass Damper, Ferrari aero and Spyker's rotary damped rear end

#F1 2015 Merc added an extra cooler with inlets around the roll hoop to help the cars cooling in the thin air of Mexico

@Specter__Harvey @xavigazquez @alfaromeoracing @Graining_es @AbelCaroR @pablodevillota @jeroitim @TimoteoBriet @AerodinamicaF1 @AeroGandalf @FernandoWRC @hugoRP9 @JVilladelpratF1 So, the Vader 'grille' is just an S-Duct....! 🤔

Great to hear Ducati taking up the supply of @motogp Moto-e. But a chance to look back at the @EnergicaMotor that got it going

@cranclive @forduk Quite a partnership of engine and chassis

Some BAR CAD from back in the day - @ScarbsTech archive

Re: the Sainz crash
The FIA now have both the safety data recorder and the high speed camera recording to look at
The high speed camera by @MarelliTech runs at 400fps to record the driver's head movement during the crash
It was mounted on the chassis, but is now in the halo

When #F1 rocked up at Zandvoort in June 1967 these pair made their debut.

From the @scarbstech archives, some old hand-drawn colourised drawings.
