Craig Scarboroughさんのイラストまとめ

@Nefos_tweets @MercedesAMGF1 It's a high frame rate camera to capture driver head movement in a crash

@el_grapas

Old @Scarbstech illustrations showing the step in physical engine size from 3l V10 to 2.4l V8, c2004

A little pen drawn and photoshop drawing from the @scarbstech archive.
Showing the Super Aguri adaptations to the old Arrows chassis

Ferrari powertrain parts, auctioned back in 2005

Tyrrell 019

This then is wired with just a few cables to a connector in the quick detachable coupling.
That then mates to a corresponding connector in the steering column. Finally the loom exits the column and joins the main loom to talk to the ECU.

A little bit of old generation @FIAFormulaE arrived on the @ScarbsTech workbench today
Part of it is this pair of front fenders from a Gen1.2 FE car
Note: the front wing profile and the 28-hole range of adjustment on the flap
I just need a pair of the upper wings to complete it🤔

Scarberia Ferrari version

A couple of other @ScarbsTech archive drawings from this day in 2015
